65 & 75 Series Compact Fuel Filter/Water Separators

Specifications

 Flow Resistance: ………………………………0.75 In. Mercury

• Maximum Working Pressure:……………25 PSI (172 kPa)
• Temperature Range:…… -50° to +225°F (-45° to +107°C)
• Port Thread: ……………………………9/16-18 w/O-Ring Boss
• Height / 65: ………………………………… 6 3/8 In. (161.9 mm)
• Height / 75: ………………………………… 6 1/8 In. (155.6 mm)
• Width:………………………………………. 4 3/16 In. (106.4 mm)
• Depth: ……………………………………….. 4 3/4 In. (120.6 mm)
• Element Removal Clearance: ……….. 3 1/2 In. (88.9 mm)
• Sump Capacity:…………………………………….4 oz. (118 ml)



Flow Rates

Model 65 & 75 Series:

Recommended: …………………… 20 GPH (U.S.) (75.7 LPH)

Maximum: …………………………. 30 GPH (U.S.) (113.5 LPH)

100 Series Diesel Fuel Filter/Water Separators

Specifications

• Flow Resistance: ………………………………0.75 In. Mercury
• Maximum Working Pressure:……………25 PSI (172 kPa)
• Temperature Range:…… -50° to +225°F (-45° to +107°C)
• Port Thread:

Single Units:……………………………..9/16-18 w/O-Ring Boss

Double Units: …………………………………………….1/4-18 NPT

• Height: …………………………………….. 12 1/2 In. (317.5 mm)
• Width:………………………………………… 5 1/2 In. (139.7 mm)
• Depth: ……………………………………….. 6 1/2 In. (165.1 mm)
• Element Removal Clearance: ……….. 1 1/2 In. (38.1 mm)
• Sump Capacity:…………………………………….8 oz. (236 ml)

Flow Rates

• Single Model 100 Series:

Recommended: ……………………. 40 GPH (U.S.) (151 LPH)

Maximum: ……………………………. 65 GPH (U.S.) (246 LPH)

• Double Model 100 Series:

Recommended: ……………………. 80 GPH (U.S.) (302 LPH)

Maximum: ………………………….. 130 GPH (U.S.) (492 LPH)

Service Parts

• Elements:

101* ………………. 4 Micron Nominal (20 Absolute) Element

101-W ……………. 5 Micron Nominal (25 Absolute) Element

101-30……………. 9 Micron Nominal (40 Absolute) Element

• Gaskets:

100-GK …… Complete Gasket Kit

• Kits:

100-DEPR KIT….Depressurizer Kit (See Accessories Page)

100-MNTG KIT…………………………….. Mounting Bracket Kit

150 Series Diesel Fuel Filter/Water Separators

Specifications

• Flow Resistance: ………………………………0.75 In. Mercury
• Maximum Working Pressure:……………25 PSI (172 kPa)
• Temperature Range:…… -50° to +225°F (-45° to +107°C)
• Port Thread:

Single Units:……………………………….7/8-14 w/O-Ring Boss

Double Units: …………………………………………….3/4-14 NPT

• Height: …………………………………….. 14 1/4 In. (368.3 mm)
• Width:……………………………………………….6 In. (152.4 mm)
• Depth: ……………………………………. 6 11/32 In. (161.1 mm)
• Element Removal Clearance: ………………2 In. (50.8 mm)
• Sump Capacity:…………………………………….8 oz. (236 ml)

Flow Rates

• Single Model 150 Series:

Recommended: ……………………. 80 GPH (U.S.) (302 LPH)

Maximum: ………………………….. 100 GPH (U.S.) (378 LPH)

• Double Model 150 Series:

Recommended: ………………….. 160 GPH (U.S.) (604 LPH)

Maximum: ………………………….. 200 GPH (U.S.) (757 LPH)

200 Series Diesel Fuel Filter/Water Separators

Specifications

• Flow Resistance: ………………………………..1.0 In. Mercury
• Maximum Working Pressure:……………25 PSI (172 kPa)
• Temperature Range:…… -50° to +225°F (-45° to +107°C)
• Port Thread:

Single Units:……………………………….7/8-14 w/O-Ring Boss

Double Units: …………………………………………….3/4-14 NPT

• Height: …………………………………….. 16 3/4 In. (425.5 mm)
• Width:………………………………………… 7 1/2 In. (190.5 mm)
• Depth: ……………………………………….. 7 3/4 In. (196.9 mm)
• Element Removal Clearance: ……….. 2 1/2 In. (63.5 mm)
• Sump Capacity:…………………………………..24 oz. (708 ml)
• Top to Inlet Clearance:…………………. 2 5/8 In. (66.7 mm)
• Top to Outlet Clearance:………………. 2 5/8 In. (66.7 mm)

Flow Rates

• Single Model 200 Series:

Recommended: ………………….. 120 GPH (U.S.) (454 LPH)

Maximum: ………………………….. 200 GPH (U.S.) (757 LPH)

• Double Model 200 Series:

Recommended: ………………….. 240 GPH (U.S.) (908 LPH)

Maximum: ……………………….. 400 GPH (U.S.) (1,514 LPH)

Service Parts

• Elements:

201* ………………. 4 Micron Nominal (20 Absolute) Element

201-W ……………. 5 Micron Nominal (25 Absolute) Element

201-30……………. 9 Micron Nominal (40 Absolute) Element

• Gaskets:

200-GK …… Complete Gasket Kit

• Kits:

200-DEPR KIT….Depressurizer Kit
